Five riding modes
deliver the speed and power to own the road as a Class 1, 2, or 3 eBike.* New
simplified labels, including Eco, Tour, Sport, Sport+, & Turbo, allow
riders to choose their riding experience.
An ergonomic
below-the-bar trigger throttle on the left-hand side is easily engaged with
your thumb while simultaneously eliminating joint fatigue.
A 500W rear hub motor
(1092W peak) with 55Nm of torque supplies power and speed quicker than ever
before. Stealth M24 technology delivers a quieter motor experience without
sacrificing power.
An integrated & removable
48V, 10.4Ah (500Wh) lithium-ion battery certified to UL 2271 makes for a clean
design while powering your ride for up to 50 miles on a single charge.** The
XP4 is also certified to UL 2849.† Removing the battery from the frame is a
breeze with the side-facing key port location.
Turn your bike on and
off with the push of a button, and start riding without having the key in the
battery! Keys are needed to remove the battery from the bike frame only. We’ve
listened to our loyal riders, and you can now ride key-free!
A new rear rack design
integrated into the bike frame holds up to 150lbs and features bosses for
mounting various accessory combinations. Add a LevelUp Rack (sold separately)
on top of the rack to unlock even more accessory combinations!
The LevelUp Rack (sold separately) can be added
to the integrated rear rack and has a built-in mounting window to easily
install children's seats like the Thule Maxx Yepp Seat. If they have outgrown a
standard child seat, our Buddy Seat (sold separately) contains an
open padded seat, handlebars, and foot pegs that allow you to bring them along
for the ride!***
A custom color TFT
display featuring a detachable mount and a USB-C port. You’ll find trip,
battery, & power intelligence on the go. New intuitive drop-down menus make
navigating the settings on your eBike easy to understand & allow users to
customize their ride settings based on preference. The IP-X5-rated display
ensures greater water resistance.
Puncture-resistant 20” x
3” tires are perfect for mixed terrains and make for a smoother ride. The new
custom tread pattern has less rolling resistance for better power efficiency
and delivers an ultra-quiet experience. Slime is installed to prevent flat tires—at
no additional cost.
Our proprietary
in-house-designed torque sensor programming will give you smoother power
distribution and a better riding experience. It is designed to manage power
output based on the rider’s pedaling effort. With this programming experience,
riders can reach higher speeds easily and with more control than ever before.
An 11-32 tooth, 8-speed
freewheel paired with a Shimano Altus derailleur and a below-the-bar trigger
shifter allows you to swiftly change gears while riding to create pedaling
efficiency and an easier riding experience at higher speeds.
Forged aluminum,
56-tooth custom chainring is the perfect ratio for effortless 20-inch wheel
pedaling.
A KMC Z8 steel chain
with inner plate chamfering offers consistent tension and smooth transitions
between shifting for a secure performance throughout your ride.
Get ultimate stopping
power with 602 hydraulic brakes paired with 180mm rotors (2.3mm thick), making
it as easy to stop as it is to go, whether in wet or dry conditions. Paired
with ergonomically designed aluminum brake levers for durability.
An integrated safety
system, featuring a new bright 90-lumen headlamp with side amber lights and a
brake-activated rear light powered by the internal battery, allows you to be
seen at any time of day.
Alert drivers, riders,
and people nearby with our turn signals. Simply use the left or right arrows on
the button pad to turn on the blinkers on either side of the rear light.
The front fork provides
shock absorption for a smooth and comfortable ride. Adjust the tension or lock
it out to tailor each ride to your preference based on payload capacity and
weight distribution.
A heavy-duty steel
side-sweeping kickstand located near the chainstay keeps the eBike upright.
Polypropylene fenders
with a flared tail protect you and your ride from debris. The flexible material
is damage-resistant and helps ensure long-term durability.
Custom-designed 6000
Series Aluminum quick-release pedals with splined inserts allow for easy,
tool-free removal and installation. The new shape of the pedals improves foot
traction for an optimal experience.
Full-length ergonomic
lock-on grips add comfort so you can ride longer. The plastic sleeve inside
helps lock the grips into place and also allows the grips to be easily removed.
A custom-designed saddle
complements a sporty look while adding comfort so you can ride longer.
- Adjustable Handlebar Stem
Ride longer and more
comfortably in an upright cruising position with our new zero-degree stem,
which shortens the handlebar reach. Plus, telescoping functionality allows
riders to reach a wide range of heights while maintaining comfort and
stability.
Customize the bike to
your perfect size by adjusting the seat post height; simply open the
quick-release collar and slide the post to your preferred height and lock it in
place by closing the collar.
A foldable hinge at both
the handlebar stem and frame guarantees your ride will fit into virtually any
compact space. Remove the pedals and the seat post in seconds for easy and
lightweight transport.
Total bike weight is
62lbs without the battery installed. The XP4 battery weighs 7lbs.
An auxiliary charging
port near the bottom bracket provides riders with the option to charge the
eBike without removing the battery. The XP4 comes standard with a 2amp charger
for 4-6 hour charging, but a 5amp Fast Charger can be purchased
separately, which can charge the standard battery in as little as 2 hours.
The newly designed, more
aesthetic XP4 frame is lightweight and features sturdy 6000 series aluminum
with mounting points for various accessory combinations.
20amp internal
controller is IP-X5 rated and potted for weatherproofing and thermal
management.
Packaging components are
biodegradable and easily recyclable.
Stratus White, Tempest
Gray
Our ebikes are built with industry-leading safety certifications
so you can have peace of mind riding in almost any condition. A US-based
bicycle testing lab put the XP4 through the rigorous ISO 4210 standard testing
process.
We ensure that the electrical and battery components are
manufactured to the industry standard. The Lectric XP4 is certified to UL 2849.
Additionally, the XP4's lithium-ion battery is certified to UL 2271.
